Critical damping is the

The correct option is b smallest amount of damping for which no oscillation occurs in free vibration the system with critical damping returns to equilibrium in the fastest time without any oscillation. in critically damped free vibrations, the damping force is just sufficient to dissipate the energy within one cycle of motion. the system never executes a cycle, it approaches equilibrium with exponentially decaying displacement..

Critically Damped System (ξ = 1)

Critically damped system(ξ=1): If the damping factor ξ is equal to one, or the damping coefficient c is equal to critical damping coefficient "c c ", then the system is said to be a critically damped system.
Two roots for critically damped system are given by S 1 and S 2 as below:
For ξ = 1 ξ=1 ξ = 1 ; S 1 = S 2 = − ω n S_1 = S_2 = -\omega_n S 1 = S 2 = − ω n Here both the roots are real and equal, so the solution to the differential equation can be given by
Now differentiating equation (1) with respect to ‘t’, we get:

Now, let at t = 0 t = 0 t = 0 : x = X 0 x = X_0 x = X 0 t = 0 t = 0 t = 0 : x ˚ = 0 \mathring x =0 x ˚ = 0

Substituting these values in equation (1):

Same way, from equation (2), we get

Now putting the values of A and B in equation (1), we get:

From above equation (5), it is seen that as time t increases, the displacement x decreases exponentially.

The motion of a critically damped system is aperiodic (aperiodic motion motions are those motions in which the motion does not repeat after a regular interval of time i.e non periodic motion) and so the system does not shows vibrations.

For critically damped systems, if a system is displaced from its initial position, it will try to reach its mean position in a very short time.

Critically damped systems are generally seen in hydraulic doors closer as it is necessary for the door to come to its initial position in a very short time.
